ROG, Strix, TUF Gaming and ProArt motherboards feature upgraded connectivity, passive chipset cooling and exclusive overclocking features

Contents
The ROG Crosshair VIII Extreme holds nothing backThe ROG Crosshair VIII Extreme boasts the highest-end hardware ever put in an ASUS X570 motherboard. The VRM has a 18+2 stage design with 90-ampere power stages for clean, efficient power delivery to drive the 16-core AMD Ryzen 9 5950X processor. Cooling is handled by a pair of large aluminum heatsinks that are connected by a heatpipe to ensure rapid and even heat dissipation. The forged aluminum I/O cover not only adds to the board’s aesthetics, it’s also an integral part of the VRM heatsink by increasing the surface area for heat exchange. The M.2 heatsink at the center of the motherboard features the 2-inch LiveDash OLED display that shows vital system stats like temperatures and voltages, or it can display custom graphics and animations. The Crosshair VIII Extreme includes all the cooling and overclocking features hardcore enthusiasts demand. Voltage measurement points, onboard controls, mode switches and the Q-Code POST boot code display provide an overview during overclocking.The Crosshair VIII Extreme can handle up to five PCIe® 4.0 SSDs: one under the upper M.2 heatsink, two under the lower M.2 heatsink, and another two vertically mounted on the exclusive DIMM.2 card. The SSD’s proximity to the heatsinks ensures optimal temperatures for sustained performance. Each SSD is easily secured by the new Q-Latch mechanism.For users looking to create elaborate cooling rigs, the Crosshair VIII Extreme includes four standard fan headers, two pairs of connectors for pumps and radiators, plus two HydraNode headers that can power and monitor up to three compatible fans each. The connectors include liquid input, output and flow sensors to allow builders with custom loops to monitor the state of their setup. Builders can also look forward to more customization possibilities with the inclusion of three Gen 2 addressable RGB LED headers, a standard four-pin RGB connector and an ARGB splitter.Maximize creative potential with ASUS ProArt X570-Creator WiFiROG Strix X570-E Gaming WiFi II: The latest tech with essential ROG DNATUF Gaming X570-Pro WiFi II: Rock-steady and battle-readyPricingAvailability



KEY POINTS

  • Latest X570 motherboards feature an upgraded power design and rich connectivity, including WiFi 6E and Thunderbolt 4
  • Exclusive Dynamic OC Switcher enables new overclocking options to maximize single- and multi-threaded performance with AMD Ryzen CPUs
  • Passive chipset cooling: Comprehensive thermal designs unleash the full performance of the X570 chipset without an active cooling fan
  • Additional user-friendly features include BIOS FlashBack, M.2 Q-Latch and addressable RGB LED headers



SINGAPORE — ASUS today announced the addition of the ROG Crosshair VIII Extreme, ROG Strix X570-E Gaming WiFi II, TUF Gaming X570‑Pro WiFi II and ProArt X570-Creator WiFi motherboards to its X570 range. The ROG Crosshair VIII Extreme packs the latest ROG innovations into an EATX form factor that’s perfect for custom gaming PCs or overclocking rigs. The ROG Strix X570-E Gaming WiFi II distills the most essential ROG features into a stylish platform for discerning gamers and enthusiasts. The balanced TUF Gaming X570-Pro WiFi II is poised to perform in speedy, stealthy gaming builds. And the ProArt X570-Creator WiFi is ready for content creators, developers, and other professionals who need unquestionable stability and broad connectivity for their work.

These new models feature passive chipset cooling, improved power performance and more capable networking hardware. Some models also include Thunderbolt 4 connectivity and overclocking features to keep PC DIY enthusiasts, gamers, and system integrators at the forefront of innovation.

The ROG Crosshair VIII Extreme and ROG Strix X570-E Gaming WiFi II offer the new ASUS-exclusive Dynamic OC Switcher for those looking to get the most out of the AMD Ryzen CPU under all workloads. Until now, manually overclocking a Ryzen CPU meant maximizing all-core clock speeds at the expense of the high light-load boost clocks that are so important for general system responsiveness.

Dynamic OC Switcher lets overclockers have the best of both worlds. When this feature is enabled, compatible motherboards will automatically switch between pushing light-load clocks to the limit with AMD Precision Boost Overdrive and multi-core clocks to the max with a user’s chosen manual overclock settings. Dynamic OC Switcher is also available on the previously introduced ROG Crosshair VIII Dark Hero motherboard.

The inclusion of BIOS FlashBack enables firmware updates with a USB stick even when a CPU or memory isn’t installed. In addition, ASUS Q-Fan software allows users to tweak fan curves for the best balance of noise and airflow. Cooling is further aided by dedicated AIO headers and hybrid fan headers that can detect and work with both DC and PWM fans. The motherboards provide exceptional audio, thanks to the use of high-quality audio chips and Two-Way AI Noise-Canceling technology. And for aesthetics, Aura Sync RGB lighting and Gen 2 addressable headers with advanced auto-detection features combine to give any build a unique look.

The ROG Crosshair VIII Extreme holds nothing back

The ROG Crosshair VIII Extreme boasts the highest-end hardware ever put in an ASUS X570 motherboard. The VRM has a 18+2 stage design with 90-ampere power stages for clean, efficient power delivery to drive the 16-core AMD Ryzen 9 5950X processor. Cooling is handled by a pair of large aluminum heatsinks that are connected by a heatpipe to ensure rapid and even heat dissipation. The forged aluminum I/O cover not only adds to the board’s aesthetics, it’s also an integral part of the VRM heatsink by increasing the surface area for heat exchange. The M.2 heatsink at the center of the motherboard features the 2-inch LiveDash OLED display that shows vital system stats like temperatures and voltages, or it can display custom graphics and animations. The Crosshair VIII Extreme includes all the cooling and overclocking features hardcore enthusiasts demand. Voltage measurement points, onboard controls, mode switches and the Q-Code POST boot code display provide an overview during overclocking.

The Crosshair VIII Extreme can handle up to five PCIe® 4.0 SSDs: one under the upper M.2 heatsink, two under the lower M.2 heatsink, and another two vertically mounted on the exclusive DIMM.2 card. The SSD’s proximity to the heatsinks ensures optimal temperatures for sustained performance. Each SSD is easily secured by the new Q-Latch mechanism.

The multitude of connectivity options offered by the Crosshair VIII Extreme include 10G and 2.5G Ethernet, WiFi 6E and Bluetooth® 5.2. It also features two Thunderbolt 4 ports that offer up to 40 Gbps of bandwidth apiece, as well as a DisplayPort for single-cable monitor connections. Eight USB 3.2 Gen 2 Type-A connectors offer 10 Gbps of bandwidth each to cater to high-speed peripherals, with one of the connectors supporting BIOS FlashBack for easy firmware upgrades. A Clear CMOS button and audio outputs including S/PDIF can be found on the back panel I/O. There are also internal headers for up to four USB 3.2 Gen 1 Type-A and two USB 3.2 Type-C® ports, with one of the Type-C ports offering 60 W Power Delivery 3.0 for fast charging of devices.

For users looking to create elaborate cooling rigs, the Crosshair VIII Extreme includes four standard fan headers, two pairs of connectors for pumps and radiators, plus two HydraNode headers that can power and monitor up to three compatible fans each. The connectors include liquid input, output and flow sensors to allow builders with custom loops to monitor the state of their setup. Builders can also look forward to more customization possibilities with the inclusion of three Gen 2 addressable RGB LED headers, a standard four-pin RGB connector and an ARGB splitter.



Maximize creative potential with ASUS ProArt X570-Creator WiFi

The ASUS ProArt X570-Creator WiFi is the first ASUS ProArt motherboard to use the X570 platform. It delivers maximum performance and stability for users who depend on their PC or workstation to make a living: 3D artists, CAD and CAM designers, audio and video producers, and even software developers.

The ProArt X570-Creator WiFi features two Thunderbolt 4 USB-C ports with 40 Gbps of bandwidth and 15 W Power Delivery charging support on its rear panel to cater to audio-visual gear and high-speed external storage devices. The stainless steel back panel includes DisplayPort input for compatibility with Thunderbolt displays, along with four USB 3.2 Gen 2 and four USB 3.2 Gen 1 ports. There’s also an additional USB 3.2 Gen 2 Type-C internal header for the front panel. For networking, the ProArt X570-Creator WiFi offers 10G and 2.5G Ethernet, along with WiFi 6E and Bluetooth 5.2.

The 14+2 power design of the motherboard’s VRM and ProCool II solid-pin power connectors make it ready for the most powerful Ryzen CPUs. Large heatsinks cover the VRM power stages, X570 chipset and three M.2 slots, and the inclusion of the Q-Latch mechanism allows for tool-free installation of NVMe drives.

The ProArt X570-Creator WiFi features copper accents that stand out against the pure black motherboard hardware. Users can customize the look of their build via the three Gen 2 addressable RGB headers and the standard RGB strip connector.

In terms of software, the ProArt X570-Creator WiFi includes the ASUS Control Center Express remote IT asset monitoring and management software, plus the ProArt Creator Hub application that enables users to monitor and optimize the system, as well as control color calibration for compatible monitors.

ROG Strix X570-E Gaming WiFi II: The latest tech with essential ROG DNA

The ROG Strix X570-E Gaming WIFI II motherboard builds on the legacy of its predecessor, offering a combination of high-end components, smart software and passive chipset cooling on a single board. The CPU VRM features a 12+4 stage design with ProCool II 8+4 pin auxiliary connectors.

Like the top-end ROG Crosshair VIII Extreme motherboard, the Strix X570-E Gaming WiFi II features exclusive Dynamic OC Switcher technology to help users get the most out of the Ryzen CPU, regardless of workload. Additionally, the onboard Q-Code display, diagnostic LEDs and OptiMem II trace layout help overclockers achieve peak performance. To keep things cool, there are ample cooling options with five fan headers plus a dedicated AIO and pump headers. The PCIe 4.0 M.2 slots at mid-board and below the chipset heatsink can accept storage devices up to 110 mm long, and both come padded with thick aluminum heatsinks.

WiFi 6E and Bluetooth 5.2 offer easy connectivity with the latest routers and peripherals, with 2.5G and gigabit Ethernet ports still available for those who prefer a wired connection. The rear panel boasts seven USB 3.2 Gen 2 Type-A and one USB 3.2 Gen 2 Type-C ports. Onboard headers can provide another USB 3.2 Gen 2 port, along with two USB 3.2 Gen 1 and four USB 2.0 connectors. There are two Gen 2 addressable headers and a pair of standard RGB connectors.

An ROG SupremeFX S1220A codec chip with an integrated headphone amplifier has a 120 dB signal-to-noise ratio for impeccable audio playback. The inclusion of Two-Way AI Noise Cancelation cleans up background noise for crystal-clear voice communication during gaming.

TUF Gaming X570-Pro WiFi II: Rock-steady and battle-ready

The TUF Gaming X570-Pro WiFi II motherboard features a 12+2 DrMOS VRM and 8+4 pin ProCool auxiliary power connectors. The large aluminum VRM heatsinks and a new passive chipset heatsink keep both the CPU and the X570 chipset cool for sustained performance without throttling. The main metal-encased PCIe slot and both M.2 slots are all connected with PCIe 4.0 for maximum available bandwidth. Each slot includes the Q-Latch mechanism to easily secure each SSD in its place. For networking, the TUF Gaming X570-Pro WiFi II features 2.5G Intel® Ethernet, WiFi 6E and Bluetooth 5.2.

A Realtek AL897 codec with integrated headphone amplifier and automatic impedance detection ensures high-quality audio for music and games. The addition of Two-Way AI Noise Cancelation ensures clear communication during gaming or video conferencing.

Users can enhance the aesthetics of their TUF Gaming X570-Pro WiFi II build via one Gen 2 addressable and two standard RGB headers. Four fan headers and a dedicated AIO header allow for the creation of any mainstream cooling setup with ease.



Availability & Pricing

Pricing

ASUS ROG Crosshair VIII Extreme – $1449
ASUS ROG Strix X570-E Gaming WiFi II – Coming Soon
ASUS TUF Gaming X570-Pro WiFi II – Coming Soon
ASUS ProArt X570-Creator WiFi – $669

Availability

ASUS Sim Lim Square authorized retailer store



Specifications[i]

Model ASUS ROG Crosshair VIII Extreme ASUS ROG Strix X570-E Gaming WiFi II
CPU Socket AM4 AM4
Chipset AMD X570 AMD X570
Form Factor EATX ATX
Teamed power architecture 18+2 12+4
Memory # Slots, Maximum Capacity 4 x DIMM;
Max. 128 GB DDR4
4 x DIMM;
Max. 128 GB DDR4
Speed (MHz) 5100 (OC) 5100 (OC)
OptiMem OptiMem III OptiMem II
Graphics Output N/A HDMI® 2.0/ DisplayPort 1.2
Multi-GPU Support NVIDIA 2-Way SLI® N/A
Expansion Slots PCIe® 4.0 x16 2 x PCIe® 4.0 x16
(@ x16 or x8/x8)
2 x PCIe® 4.0 x16
(@ x16 or x8/x8)
1 x PCIe 4.0 x16 (@x4)
PCIe® 4.0 x1 1 x PCIe® 3.0 x1 2
Thunderbolt Support 2 x Thunderbolt 4 (onboard) N/A
Storage & Connectivity SATA 6 Gb/s 6 8
M.2 1 x 2280 (PCIe® 4.0 x4 & SATA)
2 x 2280 (PCIe 4.0 x4)
2 x DIMM.2 (PCIe® 4.0 x4 & SATA)
1 x 22110 (PCIe® 4.0 x4 & SATA) from CPU
1 x 22110 (PCIe® 4.0 x4 & SATA) from PCH
Front Panel Type-C® Connector 2
1 x USB 3.2 Gen 2×2
1 x USB 3.2 Gen 2
1 x USB 3.2 Gen 2
USB 4 2 (2 x Type-C® at the rear) N/A
USB 3.2 Gen 2×2 1 (Type-C® at the front) N/A
USB 3.2 Gen 2 9 (1 x Type-C® at the front, 8 x Type-A at the rear) 9 (1 x Type-C® at the front, 7 x Type-A, 1 x Type-C® at the rear)
USB 3.2 Gen 1 4 (4 x Type-A at the front) 2 x at the front
USB 2.0 4 (4 x Type-A at the front) 4 x at the front
Wireless WiFi 6E WiFi 6E
Networking Ethernet 1 x Intel® I225-V 2.5Gb
1 x Marvell® AQtion AQC113CS 10Gb
Intel® I211AT
Realtek® 2.5G LAN
LANGuard Y Y
Audio Audio Codec ALC 4082 SupremeFX S1220A
Impedance Sense Y Y
Audio Amp ESS® SABRE9018Q2C DAC Dual headphone amps
Audio Cover Y Y
LED Illuminated Audio Jacks Y N/A
Japanese Capacitors Y Y
Audio Effects Sonic Studio III +
Sonic Studio Virtual Mixer
Sonic Radar III
DTS® Sound Unbound
Two-Way AI Noise Cancelation
ROG CLAVIS Type-C USB DAC bundled
Sonic Studio III +
Sonic Studio Virtual Mixer
Sonic Radar III
DTS® Sound Unbound
Two-Way AI Noise Cancelation
Cooling Onboard Fan Headers 8 x PWM/ DC fans
ROG Fan Controller bundled
7 x PWM/DC fans
Heatsinked M.2 5 2
AI Networking (GameFirst VI) Y GameFirst V
Two-way AI Noise-Cancelation Y Y
Aura Sync Y Y
RGB Header 3 x ARGB; 1 x onboard RGB;
6 x ARGB on the bundled ROG Fan Controller
2 addressable headers and 2 RGB headers
Pre-mount I/O shield Y Y
CPU Power Connector 8-pin + 8-pin 8 + 4 pin
ProCool connector with solid pins ProCool II ProCool II
COM N N/A
SPI / TPM N Y



Model ASUS TUF Gaming X570-Pro WiFi II ASUS ProArt X570-Creator WiFi
CPU Socket AM4 AM4
Chipset AMD X570 AMD X570
Form Factor ATX ATX
Teamed power architecture 12+2 14+2
Memory # Slots, Maximum Capacity 4 x DIMM;
Max. 128 GB DDR4
4 x DIMM;
Max. 128 GB DDR4
Speed (MHz) 5100 (OC) 5100 (OC)
OptiMem OptiMem OptiMem II
Graphics Output DisplayPort / HDMI1.4b HDMI 2.1(4K @ 60 Hz)
Multi-GPU Support N/A N/A
Expansion Slots PCIe® 4.0 x16 1 x PCIe® 4.0 x16 (@ x16)
1 x PCIe® 4.0 x16 (max. @x4)
2 x PCIe® 4.0 x16
(@ x16 or x8/x8)
1 x PCIe® 4.0 x16 (@ x4)
PCIe® 4.0 x1 1 x PCIe® 4.0 x1 0
Thunderbolt Support N/A 2 x Thunderbolt 4 (onboard)
Storage & Connectivity SATA 6 Gb/s 6 6
M.2 2 x 22110 (SATA & PCIe® 4.0 x4 mode) 1 x 22110 (PCIe® 4.0 x4 & SATA) from CPU
1 x 2280 (PCIe® 4.0 x4) from CPU
1 x 22110 (PCIe® 4.0 x4 & SATA) from PCH
Front Panel Type-C® Connector 1 x USB 3.2 Gen 2 1 x USB 3.2 Gen 2
USB 4 N/A 2 (2 x Type-C® at the rear)
USB 3.2 Gen 2×2 N/A N/A
USB 3.2 Gen 2 4 (1 x Type-C® at the front, 2 x Type-A, 1 x Type-C® at the rear) 5 (1 x Type-C® at the front, 4 x Type-A at the rear)
USB 3.2 Gen 1 6 (4 x at the rear, 2 x at the front) 6 (2 x Type-A at the front, 4 x Type-A at the rear)
USB 2.0 4 at the front 6 at the front
Wireless WiFi 6E WiFi 6E
Networking Ethernet 1 x Intel® I225-V 2.5Gb 1 x Intel® I225-V 2.5Gb
1 x Marvell® AQtion AQC113CS 10Gb
LANGuard Y Y
Audio Audio Codec Realtek ACL897 Realtek S1220A
Impedance Sense Y Y
Audio amp Internal Amp Internal Amp
Audio Cover Y Y
LED Illuminated Audio Jacks N/A N/A
Japanese Capacitors Y Y
Audio Effects DTS Custom for Gaming Headsets
Two-Way AI Noise Cancelation
Two-Way AI Noise Cancelation
Cooling Onboard Fan Headers 6 x PWM/DC fans 7 x PWM/DC fans
Heatsinked M.2 1 2
AI Networking (GameFirst VI) N/A CreationFirst
Two-way AI Noise-Cancelation Y Y
Aura Sync Y Y
RGB Header 1 addressable header and 2 RGB headers 3 addressable headers and 1 RGB header
Pre-mount I/O shield Y Y
CPU Power Connector 8 + 4 pin 8 + 4 pin
ProCool connector with solid pins ProCool ProCool II
COM Y Y
SPI / TPM Y Y
